Elevated Copper Levels in Oil Analysis Reports-Doug's Tip of the Month

What can High Copper Levels mean?

Recently I have reviewed many Used Oil Analysis reports that indicated elevated Copper levels. Although Copper is considered a Wear Metal, there are instances or situations that can occur where higher than normal levels of copper can exist. This can also be true with other Wear Metals like iron, lead, aluminum, and chromium, where the analysis readings were raised or lower than normal.

Back to Copper. There are many reasons why copper could be high, but it usually comes down to either wear, or the copper is leaching into the oil from cooler lines or components due to new equipment break in. By looking at other wear metals and elements such as tin and/or zinc for instance, equipment wear can be rules out or confirmed. If the other wear mechanisms are not present in the oil sample analysis, then most likely the culprit for high copper levels is in fact the oil cooler and components.

The break in or leaching of copper levels into the oil can be either slowed or increased depending on Diesel Engine Oil formulations. Sometimes, converting from one brand to another these levels of copper would increase or decrease. Therefore, it is always important to look at the analysis reports and the elements in it’s entirety before drawing any conclusions.

Most often we have seen these issues with Caterpillar equipment. In 2003 CAT issued bulletin SEBD9318-00 to address this issue. It says in part “These elevated copper levels can be dramatic. Customers that observe these elevated copper levels are very concerned about excessive wear or component failure. In most cases, the customer should not be concerned about these elevated copper levels: the condition does not usually indicate excessive wear and/or component failure. However, it is important to understand the cause of the condition.”   Again, it is important to review the UOA Reports completely to have a better understanding of the oil and equipment condition.

Read More

Doug's Tip of the Month - Oil Analysis Flagging Limits

An oil analysis report contains results on as many as 40 different parameters that each have acceptable ranges identified. The type of oil, its formulation, how it should be maintained, and the operating conditions all are considered when evaluating an oil sample and setting acceptable ranges. Also considering the type of equipment and the operating environment is just as important.

An acceptable oil analysis program should consist of these basic components; standard processes for the establishment of normal ranges, along with the identification of limits and a reliable system for recognizing failure modes. Most labs offer comments and recommendations in the form of flags that are patterned after green, yellow and red traffic lights. Yellow and red flagged parameters indicate that a threshold has been passed and further action is required on the part of the end user; green flagged information indicates an item is within range, and is archived for trending. Some parameters, such as particle counts, only have upper limits. Other parameters, such as oxidative stability, only have lower limits. Parameters such as viscosity, that measure stability, have both upper and lower limits. There is not a universal approach for setting alarm limits. Also, some parameters and stats on the lab report are not critical to that specific piece of equipment, so not every oil analysis parameter needs an alarm limit.

Because oil analysis is as much expertise as formulae and there are so many considerations involved, most labs do not publish limit information. The issue for end-users is who sets the range and who to believe—formulator, OEM, lab, industry, association such as ASTM—and why.

There are four traditional absolute methods for determining oil analysis ranges and flagging limits.



These methods are:

  1. Industry standards. These are generic limits placed on machines that are grouped according to working pressure or type (e.g., gearboxes or hydraulic systems). These standards are generally considered baseline. Limits set by industries and associations often involve equipment with strict safety and reliability requirements. These limit values should be carefully considered.
  2. Statistical alarms. These are based on common distribution functions that are usually built into software.
  3. Trend-based or rate-of-change limits. These define an unacceptable departure from a usual level. There are three ways of developing trend or rate of-change alarms:
    1. Relative magnitudes. This identifies a significant change in magnitude.
    2. Rolling average. This compares the current value to the average of several historical measurements.
    3. Weighted delta settings. This uses a weighting method that requires a very large change to occur before an alarm is tripped for a small measured value. As the measured value increases, the required percentage change decreases.
  4. No predefined limits. These are judgment-based and rely on the availability of experienced analysts familiar with the type of machinery being monitored. A qualified technical data analyst will have relevant industry experience and bring value to the recommendations by considering a multitude of factors rather than focusing on a single test result and evaluating it without consideration of other key data. In addition to statistical anomalies, a data analyst reviews rates of change and the amount of time on both the equipment and fluid.



Consider working with your Technical Advisor and a Lab to help determine any changes to flagging limits for the end-user.





Read More

Are You Maximizing your Equipment's Efficiency?

We talk a great deal around here about proactive solutions - ideas and programs that, with a little time and capital ultimately save us time, money, and maybe most importantly - save us from the headaches of unanticipated problems. A major proactive plan that's been awesome for ourselves and several of our customers is Oil Analysis.

What if you could get an analysis emailed to you every time you PM'ed your fleet  - whether that was tractors, heavy construction equipment, or a specialty machine?

What if that analysis could tell you your equipment may have a slow coolant leak, or your system showed a little corrosion?

With that kind of heads up, you could proactively schedule down time for that equipment to be repaired without dealing with the chaos from equipment failure.

What if on top of that, your report let you maximize oil drain intervals?

With that info, you could schedule your maintenance out more easily, and save on your overall lubricant spend in many cases.

CITGO has a calculator on their site you can calculate what oil analysis may save your business based on mileage, fleet size, etc

(CITGO offers this analysis to Dennis K Burke customers for FREE on qualified engine oils, so you can try it no risk and see if it adds value to your bottom line..... Dont use engine oil? No problem - Dennis K Burke offers an analysis program for Industrial & Specialty Equipment as well )

You can read more about Oil Analysis benefits in general (especially for industrial equipment) on the WearCheck USA site here: http://www.wearcheck.com/

The peace of mind from knowing your fleet is running at maximum efficiency, and your mechanics have a heads up of small engine issues before they result in catastrophic failures and downtime alone is worth it.

If you would like more info on Oil Analysis in general, or how DKB can help you get started, fill out the contact form on the right or call us anytime.
